The Class II Double-Stack Amber 24-LED Warning Beacon delivers professional warning visibility with a distinctive double-stack LED design, increased 24-LED configuration, and a versatile selection of 18 flash patterns.
Designed for 12–24V DC electrical systems, this beacon works across a broad range of light-duty and heavy-duty vehicle applications. Its 3-bolt mounting configuration provides a permanent installation for work vehicles and equipment that regularly require amber warning lighting.
This configuration matches the Kaper II L03-0106-DS, which is specified as a Class II double-stack beacon with 24 amber LEDs, 18 R65 flash patterns, 12–24V DC operation, 3-bolt mounting, 12" leads, an amber polycarbonate lens, and a plastic/aluminum base.
Double-Stack 24-LED Design
The double-stack configuration is the defining feature of this warning beacon.
Compared with the related single-layer configuration, the double-stack model increases the LED count to 24 amber LEDs, providing a larger warning-light configuration while maintaining the familiar beacon format. Kaper II also offers the same family in single-layer 12-LED and triple-stack 36-LED configurations.
This makes the double-stack version an excellent middle option for buyers who want more warning-light presence than a single-layer beacon without moving to the larger triple-stack configuration.
18 Selectable Flash Patterns
The beacon provides 18 selectable R65 flash patterns, giving operators flexibility to choose a warning sequence appropriate for their vehicle, fleet, or operating environment.
Multiple patterns also make this beacon particularly useful for fleet applications where warning-light operation may need to be standardized across several vehicles.
12–24V DC Operation
The 12–24V DC operating range provides compatibility across a broad range of vehicle electrical systems.
Potential applications include compatible:
12V systems — pickups, work trucks, service trucks, tow trucks, utility vehicles, and other light-duty applications.
24V systems — heavy-duty trucks, construction machinery, agricultural equipment, commercial vehicles, and industrial equipment.
Permanent 3-Bolt Mount
This model uses a 3-bolt mounting configuration, making it suitable for permanent installations rather than temporary magnetic mounting.
A fixed 3-bolt design is ideal for vehicles and equipment where the warning beacon will remain installed as part of the vehicle's regular safety and visibility equipment.
Amber Polycarbonate Lens
The exact L03-0106-DS configuration uses an amber polycarbonate (PC) lens along with a plastic/aluminum base and 12-inch electrical leads.
These specifications are particularly useful for customers matching an existing beacon by construction, wiring length, or mounting style.
Specifications
| Specification |
Details |
| Product Type |
LED Warning Beacon |
| Warning Classification |
Class II |
| Beacon Configuration |
Double Stack |
| Illumination Color |
Amber |
| Lens Color |
Amber |
| Lens Material |
Polycarbonate (PC) |
| Lighting Technology |
LED |
| LED Count |
24 Amber LEDs |
| Flash Patterns |
18 R65 Patterns |
| Operating Voltage |
12–24V DC |
| Mounting Style |
3-Bolt Permanent Mount |
| Wire Leads |
12" |
| Base |
Plastic / Aluminum |
| Primary Function |
Warning / Hazard / Vehicle Visibility |
The lens, base, lead length, and R65-pattern specifications above are confirmed for the matching L03-0106-DS configuration.
Features
- Class II LED warning beacon
- Double-stack design
- 24 amber LEDs
- 18 selectable R65 flash patterns
- 12–24V DC operation
- Permanent 3-bolt mounting
- 12-inch electrical leads
- Amber polycarbonate lens
- Plastic/aluminum base
- Suitable for compatible 12V and 24V vehicle systems
- Instant LED illumination
- Low power consumption
- Long-life LED technology
- Reduced maintenance
- Professional work-vehicle warning-light configuration
Applications & Compatibility
The Class II Double-Stack Amber 24-LED Warning Beacon is well suited for compatible:
- Work trucks
- Service trucks
- Utility trucks
- Tow trucks
- Roadside assistance vehicles
- Snowplows
- Snow-removal equipment
- Construction vehicles
- Construction equipment
- Landscaping trucks
- Agricultural equipment
- Tractors and farm machinery
- Municipal vehicles
- Maintenance vehicles
- Fleet vehicles
- Commercial trucks
- Heavy-duty trucks
- Industrial equipment
- Specialty vehicles
Amber Warning-Light Applications
Amber warning lighting is commonly used to increase recognition of vehicles and equipment engaged in work, service, towing, construction, maintenance, snow removal, agriculture, and similar operations.
Permitted warning-light classifications, colors, flash patterns, placement, and use can vary by jurisdiction and application. Verify applicable requirements before operating warning lighting on public roads.
Important Fitment Note
Before ordering, verify:
- Class II classification
- Double-stack configuration
- 24 amber LEDs
- Amber lens
- 18 flash patterns
- 12–24V DC electrical compatibility
- 3-bolt mounting configuration
- Existing mounting-hole pattern
- Available mounting clearance
- 12" electrical lead
- Wiring requirements
Marketing Callout
DOUBLE-STACK VISIBILITY. 24 AMBER LEDs. 18 FLASH PATTERNS.
A professional Class II 12–24V warning beacon with permanent 3-bolt mounting for compatible work trucks, commercial vehicles, construction equipment, agricultural machinery, and fleets.
